AD / DD Merit Line Models EMIcorp.com

This versatile conveyor can be used for a wide range of uses including under the press, along side the press or wherever a three-plane conveyor is needed. Nose-over makes it perfect for feeding into large containers or onto trunklines.

Direct Drive drive train requires less maintenance Double V-guided belt tracking extends belt life

DDZ Steel Frame Cleated Belt Z Conveyor ADZ Aluminum Frame Cleated Belt Z Conveyor

Direct Drive configuration with 1/3 hp AC motor. 4-40 FPM variable speed drive. 50 lb. maximum load. 12-gauge steel construction or 1/8" anodized aluminum. Double V-guided, FDA approved, white PVC belt with 1" tall flexible cleats on 18" centers. 4" tall side rails, lapped over conveyor belt. Leg sets and swivel castors included. 15' power cord included. Pre-wired ready to run (except polyphase systems which require some customer wiring). Control wiring contained in liquid-tight conduit and connectors. Units ship fully assembled. 3-Year Limited Warranty, see page 3.

Standard belt widths: 6", 9", 12", 18", 24", 30" Standard Combined lengths: up to 15' at 1' increments

*Consult your EMI representative for other widths and lengths
