PE-2520 PE-2540 PE-2560 PE-25100/200 PE-2520 (6 bar) PE-2540 (6 bar) PE-2560 (6 bar) PE-25100/200 (6 bar)

EMIcorp.com 13: GENERAL PURPOSE GRIPPERS

Quick# 6240 6242 6243 6239 6241 Part# PE-2520 PE-2540 PE-2560 PE-25100 PE-25200 Price $509.00 $622.00 $685.00 $1,074.00 $1,413.00 Medium Filtered, lubricated / non-lubricated compressed air Pressure range 30-116 psi Total gripping force at 87 psi 103.4 lbf Stroke ( 0.25mm) 2x10mm 2x20mm 2x30mm 2x50mm 2x100mm Cycle air consumption 44cm

3

74cm

3

102cm

3

146cm

3

263cm

3

Maximum repeatability tolerance 0.04mm Mid-stroke detection capability Yes, see Sensor Reference Guide on page 1010 for details. Weight 700g 980g 1285g 1235g 2800g

Gripping Force

The graphs show the gripping force on each jaw, as a function of the operating pressure, the gripping tool length 'Z' and the overhanging 'X'. The force shown in these graphs refers to one jaw. The total force is double. Reference: Force: N x 0.225 = lbf Pressure: bar x 14.5 = psi

PE-2520, PE-2540, PE-2560, PE-25100 and PE-25200

Sensors available on page 717.

Parallel Gripper - PE
